Titanium Hex Nipple, High-Pressure Type
A high-pressure titanium hex nipple designed for connecting PT threads.
Featuring the excellent corrosion resistance and lightweight properties characteristic of titanium, it is suitable for piping systems handling chemicals, seawater, and specialty fluids.
Product Specifications
| Max. working pressure | S/80 equivalent |
|---|---|
| material properties | TB340 (Titanium) |
Product Details
(Unit: mm)
| Nominal size | fixed diameter | length | |
|---|---|---|---|
| H | L | ||
| PT 1/8×PT 1/8 | TNPT-0606 | 12 | 26 |
| PT 1/4×PT 1/4 | TNPT-0808 | 14 | 34 |
| PT 3/8×PT 3/8 | TNPT-1010 | 17 | 37 |
| PT 1/2×PT 1/2 | TNPT-1515 | 22 | 46 |
| PT 3/4×PT 3/4 | TNPT-2020 | 27 | 48 |
| PT １×PT １ | TNPT-2525 | 35 | 55 |
We can also manufacture products in sizes not listed, so please feel free to contact us for more information.
Since no pressure resistance test has been conducted, no pressure resistance guarantee is provided.
