316L conversion sockets (PT x NPT)
Izutsu's conversion sockets are made of SUS304 material. It serves as a joint between an American screw and a Japanese screw, and has excellent durability to withstand high pressure. In addition, they are controlled by NPT and PT gauges at our own factory.
Product Specifications
| Max. working pressure | S/80 equivalent |
|---|---|
| material properties | SUS304/316L |
| fluid | Water, air, oil, solution |
Product Details
(Unit: mm)
| Nominal size | outer diameter | length | |
|---|---|---|---|
| Dφ | L | ||
| PT 1/8×NPT 1/8 | SSPN-0606 | 18 | 28 |
| PT 1/4×NPT 1/4 | SSPN-0808 | 22 | 28 |
| PT 3/8×NPT 3/8 | SSPN-1010 | 25 | 33 |
| PT 1/2×NPT 1/2 | SSPN-1515 | 32 | 37 |
| PT 3/4×NPT 3/4 | SSPN-2020 | 38 | 42 |
| PT １×NPT １ | SSPN-2525 | 46 | 45 |
| PT １1/4×NPT １1/4 | SSPN-3232 | 55 | 52 |
| PT １1/2×NPT １1/2 | SSPN-4040 | 65 | 56 |
| PT ２×NPT ２ | SSPN-5050 | 75 | 66 |
| PT 2 1/2×NPT 2 1/2※ | SSPN-6565 | ※90 | 72 |
| PT 3 ×NPT 3※ | SSPN-8080 | ※101.6 | 82 |
| PT 4 ×NPT 4※ | SSPN-100100 | ※127 | 104 |
*Note: The 65A ,80A and 100A models are low-voltage types.*
We can also manufacture products in sizes not listed, so please feel free to contact us for more information.
